Wuxi Jin Ming Jian De Industry & Trade Co., Ltd. is one of the leading manufacturers and suppliers of 309s stainless steel sheet/plate in China. If you're going to wholesale the newest 309s stainless steel sheet/plate made in China, welcome to get pricelist from our factory. All customized products are with high quality and competitive price.
JMJDWX Steel 309s Stainless Steel Sheet/Plate is a highly alloyed austenitic stainless steel used for its excellent oxidation resistance, high-temperature strength, and creep resistance. The lower nickel content of Stainless Steel 309, compared to Stainless Steel 310, improves its resistance to hydrogen sulfide (H2S) attack at high temperatures. It is tough and ductile and can be readily fabricated and machined. SS 309S is the low-carbon version, and is recommended for applications where sensitization and subsequent corrosion by high temperature gases or condensates during shutdown may pose a problem.
- Specifications:AISI 309s, ASTM 309s
- Standard:A240 480
- Finishes:Ba surface, 2b surface, No.1 (white skin), HL (wire drawing), 8K surface have excellent surface quality and good brightness.
- Applications:metal structures, Architectural applications, Food industry, chemical and oil industry, pharmaceutical industry, nuclear industry, Naval industry, non-magnetic constructions, cryogenic service, high temperature service application Steel type
- How is it Measured:thickness X width X length
- Available Stock Sizes:1ft x 4ft, 2ft x 2ft, 2ft x 4ft, 4ft x 4ft, 4ft x 8ft, 4ft x 10ft or Cut to Size
Mill tolerances on thickness & flatness applies.Call JMJDWX Steel if you need specific sizes or grain direction.
Chemical composition and mechanical properties Of Stainless Steel 309S
chemical composition(% ) of 309s Stainless Steel Plate:
|
Element |
C |
Si |
Mn |
S |
P |
Cr |
Ni |
|
Content |
≤0.08 |
≤1.00 |
≤2.00 |
≤0.030 |
≤0.045 |
22.00~24.00 |
12.00~15.00 |
Mechanical properties of stainless steel 304L:
|
Performance |
yield strength/MPa |
Tensile strength/MPa |
Elongation /% |
Reduction of area /% |
|
Proportion |
≥ 205 |
≥ 515 |
≥ 40 |
≥50 |
Packing:
- For cold rolled stainless steel,JM steel will do PVC or interleaving paper to protect surface;
- then use waterproof paper;
- steel strip to reinforcement;
- The four corners are made of triangular iron sheet to protect the edges and corners.
Factory Show
Why choose us?
- Top 20 companies in stainless steel industry trade volume.
- Customized processing stainless steel one-stop purchase.
- Exports of stainless steel exceeded tens of billions for 5 consecutive years.
- We have a complete set of testing equipment, such as ut & ET, hydrauilc testinge quipment, spectrometer, scanning electron microscope, etc, and have passed SGS TUV certification
- JM Steel has hundreds of millions of high-end processing equipment at home and abroad, including precision cutting equipment: advanced Italian Nova stainless steel Kaiping production line, Taiwan Weitai stainless steel cross-cutting line, Taiwan Weitai stainless steel slitting line, large-scale stainless steel cold and hot rolling Flattening machine, slitting machine, etc
For More details of each item,contact our sales to know more about it.Thanks for your visiting of JMJDWX Steel,save our web.You will be more professional in steel industry.
Hot Tags: 309s stainless steel sheet/plate, China 309s stainless steel sheet/plate manufacturers, suppliers, factory
